circuit breaker EasyPact CVS100B, 25 kA, 415 VAC, 80 A nominal, TM-D thermomagnetic disconnecting device, 3P 3d - SCHNEIDER ELECTRIC EasyPact CVS LV510306

On Order

87.46

87.46 €  171.06 BGN

ex VAT

87.46 €  171.06 BGN ex VAT

Item number: LV510306

Unit of measurement: par.

Manufacturer: 50/60 Hz

Manufacturer: par.

Manufacturer: SCHNEIDER ELECTRIC

Manufacturer: EasyPact CVS

Model: EasyPact CVS

EAN: 3606480220135

- +

The EasyPact CVS100B is a 3 pole 3d fixed circuit breaker with a high level of performance and cost saving functionality. It is the optimal choice for small and medium-sized building protection applications. Tripping capability (Icu) is 25 kA rms at 415 VAC 50/60 Hz. The operating voltage is 440 VAC 50/60 Hz. This product has a built-in 80A thermo-magnetic d... View more

Description

The EasyPact CVS100B is a 3 pole 3d fixed circuit breaker with a high level of performance and cost saving functionality. It is the optimal choice for small and medium-sized building protection applications. Tripping capability (Icu) is 25 kA rms at 415 VAC 50/60 Hz. The operating voltage is 440 VAC 50/60 Hz. This product has a built-in 80A thermo-magnetic disconnect (TMD). TMD trip device provides adjustable thermal overload protection and fixed magnetic protection. This 3 pole version (105mm x 161mm x 86mm) has various optional features and accessories. EasyPact CVS100B is compliant with international standards (IEC 60947, CCC, EAC). It can be installed in Class II insulated switchboards as it is a Class II front-end device (IEC 60664-1).
No content available yet.

Specifications

Manufacturer
50/60 Hz
par.
SCHNEIDER ELECTRIC
EasyPact CVS
Model EasyPact CVS
EAN 3606480220135
Network frequency 50/60 Hz
Model EasyPact CVS
Instantaneous current protection type II Stationary/fixed
Instantaneous current protection 640 A
Connection - terminal block Screw connection
Code exclusion capability B
Contact position indicator Yes
Product or component type Circuit breaker
Product name EasyPact CVS
Standards EN 60947-2, IEC 60947-2
Mounting support Back plate
[In] rated current 80 A at 40 C
Gross weight 0.00
Net weight 0.00
